Volkswagen ID.4: Removing and installing earth wire with battery monitor control unit [J367]

The battery monitor control unit - J367- will henceforth be referred to as "battery monitor control unit".

Removing

• Disconnect battery ⇒ Rep. gr. 27 ; Disconnecting and connecting battery .
• Disconnect electrical connector -2- from battery monitor control unit -3-.

• Unscrew nut -1- from earth wire -2-.
• Remove earth wire -2- with battery monitor control unit [J367].

Installing

Install in the reverse order of removal, observing the following:

Battery monitor control unit - J367- - commissioning:

• Carry out required function/functions using ⇒ Vehicle diagnostic tester ⇒ Rep. gr. 00 ; Access to diagnoses .

Continued

Tightening torques

• ⇒ Rep. gr. 27 ; Assembly overview - battery

Commissioning battery monitor control unit [J367]

The battery monitor control unit - J367- is referred to hereafter as battery monitor control unit.

• Carry out function "Commission battery monitor control unit" using ⇒ Vehicle diagnostic tester ⇒ Rep. gr. 00 ; Access to diagnoses .
