Volkswagen ID.4: Overview of fitting locations

Overview of fitting locations - front of body

Overview shown for left side of vehicle as an example

1. Front longitudinal member cross panel

• ⇒ o3.1 verview - front longitudinal member cross panel"
• ⇒ Rep. gr. 50; Renewing front longitudinal member cross panel

2. Front wheel housing

• ⇒ o6.1 verview - front wheel housing", page 65
• ⇒ o6.2 verview - front wheel housing, part section"
• ⇒ Rep. gr. 50; Renewing front wheel housing
• ⇒ Rep. gr. 50; Renewing front wheel housing (part section)

3. Front battery tray

• ⇒ o5.1 verview - battery tray"
• ⇒ b5.2 attery tray"

4. Rear battery tray

• ⇒ o5.1 verview - battery tray"
• ⇒ b5.2 attery tray"

5. Front longitudinal member

• ⇒ o4.1 verview - front left longitudinal member, part section"
• ⇒ o4.2 verview - front left longitudinal member, part section (second separating cut)"
• ⇒ o4.3 verview - front right longitudinal member, part section"
• ⇒ o4.4 verview - front right longitudinal member, part section (second separating cut)"
• ⇒ Rep. gr. 50; Renewing front left longitudinal member, part section
• ⇒ Rep. gr. 50; Renewing front left longitudinal member, part section (2nd separating cut)
• ⇒ Rep. gr. 50; Renewing front right longitudinal member, part section
• ⇒ Rep. gr. 50; Renewing front right longitudinal member, part section (second separating cut)

6. Upper inner longitudinal member

• ⇒ o4.6 verview - upper inner longitudinal member"
• ⇒ Rep. gr. 50; Renewing upper inner longitudinal member

7. Upper longitudinal member

• ⇒ o4.5 verview - upper longitudinal member"
• ⇒ Rep. gr. 50; Renewing upper longitudinal member
